CNC lathe machine
Maximum turning diameter mm Ф450
Maximum turning diameter on tool post mm Ф310
max turning length mm 500
Max Bar bore diameter mm Ф52
Spindle nose / A2-6
Spindle bore mm Ф69
Max spindle speed rpm 4000rpm
spindle power kw 11/15kw
Chuck / 8"
Dongguan Jide Precision Machinery Technology Co., Ltd. is one of the most credible manufacturers and suppliers of cnc lathe machine in China. If you're going to wholesale high quality cnc lathe machine made in China, welcome to get quotation and free sample from our factory. All customized products are with high quality and competitive price.
CNC lathe machine adopts high-strength heavy-duty cast iron, compact structure, good strength, proper hardness, low friction coefficient, and self-lubricating. The integral box structure of the base bed greatly enhances the overall rigidity and stability of the machine tool. It has the function of absorbing vibration, which reduces tool loss and improves the quality of the workpiece. It provides users with a guarantee of high efficiency and high reliability in use. Slant bed CNC lathe is a high-precision, high-efficiency automatic machine tool. Equipped with multi-station turret or power turret, the machine tool has a wide range of technological performance, and can process linear cylinders, oblique cylinders, arcs and various threads, grooves, worms and other complex workpieces. It has linear interpolation and arc interpolation. Compensate various compensation functions, and has played a good economic effect in the mass production of complex parts.
Standard features for CNC 508 :
*Lathe machine is standard with FANUC 0ITF latest version/SIEMENS 828D
*Slant bed heavy duty casting
*Hydraulic chuck 8" Taiwan original brand CHANDOX
*cnc lathe installed with Taiwan TJ/AIMACH servo turret , With ultra-fast speed, high precision. Tool change time The maximum
distance tool change in less than 0.3 seconds.
*Hydraulic automatic tailstock
*Automatic lubrication system & coolant system
Characters as below :
1.cnc lathe casting is with the 30° inclined layout greatly improves the bending and torsion rigidity of the machine tool at work. The integrated bed base with high rigidity and high stability provides a strong guarantee for the high precision of the whole machine.
2. The spindle unit is an independent spindle (sleeve type). The high-precision spindle system has undergone rigorous dynamic balance testing, with high precision, good accuracy retention, and good thermal stability. The maximum speed can reach 4000rpm. The high precision, high rigidity, high speed and high efficiency of the spindle unit enable the whole machine to not only finish finishing, but also to perform rough machining and heavy cutting for users.
3. The tailstock is hydraulically driven, and the sleeve automatically expands and contracts with good rigidity. Users can use the panel or foot switch to control it, which saves time and effort and provides high efficiency for machine tool processing.
4. The standard configuration of SANHE/SWIFTservo turret provides users with convenient, practical and reliable machining parts.
5. The feed system is directly driven by a servo motor with good rigidity, precision and dynamic response characteristics. The machine tool is equipped with Taiwan HIWIN/THK screw guide rail, and the maximum rapid movement speed can reach: 24m/min.
6. This machine provides users with a complete hydraulic and lubrication system, using high-quality hydraulic pumps and hydraulic valves and other components to greatly reduce the failure rate. The machine tool adopts centralized quantitative automatic lubrication.
Parameters for CNC 508 8" hydraulic chuck
|
Parameter |
Name |
unit |
CNC-508 |
|
Processing Range parameters |
Maximum bed over swing diameter |
mm |
Ф550 |
|
Maximum turning diameter |
mm |
Ф450 |
|
|
Maximum turning diameter on tool post |
mm |
Ф310 |
|
|
max turning length |
mm |
500 |
|
|
Max Bar bore diameter |
mm |
Ф52 |
|
|
Spindle cylinder chuck parameters |
Spindle nose |
/ |
A2-6 |
|
Spindle bore |
mm |
Ф69 |
|
|
Max spindle speed |
rpm |
4000rpm |
|
|
spindle power |
kw |
11/15kw |
|
|
Chuck |
/ |
8" |
|
|
X/Z axis rapid feedrate |
X |
kw |
2.4 |
|
Z |
kw |
2.4 |
|
|
X travel |
mm |
225 |
|
|
Z travel |
mm |
610 |
|
|
X/Z rapid feedrate |
mm/min |
24 |
|
|
position accuracy |
mm |
±0.005 |
|
|
Repeatability |
mm |
±0.003 |
|
|
Railguide |
/ |
Roller linear guideway 45mm |
|
|
Servo turret |
Turret position |
pcs |
12T |
|
Tool holder specification |
mm |
25x25 |
|
|
Round boring holder |
mm |
Ф40 |
|
|
T-T tool change time |
sec |
0.2 |
|
|
Tailstock |
Sleeve diameter |
mm |
Ф60 |
|
Sleeve stroke |
mm |
150 |
|
|
Sleeve taper |
/ |
MT-5 |
|
|
Floor space |
L ✖W |
m |
2.46x1.86x1.82 |
|
Weight |
kg |
4000 |
Optional accessories :
*Control system : GSK25I/SYNTEC
*CNC lathe machine also have other different chuck size and working diameter and working distance /spindle bore so on ,contact us for more size details .
*More machine size available for choice
*Chip conveyor
*Tool setter
Package and delivery time :
Package : standard export package
Delivery time : 45-60days after getting deposit
FAQ :
Q1.How can l get a quotation?
A. Leave us messages about your requirement or contact us by below contact to check with your details requirement .
Q2.Can you provide a customized machines ?
A. Yes, in order to increase efficiency. we also have some special cnc lathe for professional working purpose we not listed in our catalog.
3.Can you provide training CNC machines?
A. Yes, training in our factory or if necessary . in customers spot.
4. Can you arrange shipment ?
A. No problem . we have professional export team for CIF trade term .
